1.4529 Ultra 6x Lncoloy926 Plate Incoloy Alloy 926 Super Austenitic Nickel Alloy

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1.4529 Ultra 6x Lncoloy926 Plate Incoloy Alloy 926 Super Austenitic Nickel Alloy

Brand Name : TISCO ZPSS

Model Number : 1.4529

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 200KGS

Price : 12.5 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 14 Days

Packaging Details : Export Packing

Application : Construction,chemical,Industry

Width : 1000-2000mm

Type : Plate

Standard : ASTM,JIS,AISI,EN

Length : Customer's Request,1000-6000mm or Customer's Requirement

Surface : BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D

Thickness : 0.3mm-120mm

Edge : Slit Edge

Technique : Cold Rolled Hot Rolled

Price term : CIF CFR FOB EX-WORK

Item : ISO9001 Standard

Contact Now

Ultra 6XNEN 1.4529, ASTM UNS N08926

General characteristics

6% Mo, high Ni, and N alloyed austenitic grade with extremely high resistance to both uniform and localized corrosion. Commonly used in applications to withstand chlorinated sea water also used in flue gas cleaning.

Typical applications

  • In applications to withstand chlorinated sea water
  • Flue gas cleaning
  • Process equipment in chemical industry
  • Bleaching equipment in the pulp and paper industry
  • Desalination
  • Seawater handling
  • Hydrometallurgy
  • Food and beverage
  • Pharmaceuticals
  • Heat exchangers

Product forms, available sizes and finishes

Flat
Product type Finishes Thickness Width
Cold rolled coil 2B, 2E 0,40-6,35 36-1600
Cold rolled sheet 2E 2,00-6,35 800-1600
Hot rolled coil, pickled 1D 7,00-8,00 800-1600
Quarto plate 1D 8,00-45,00 400-2700
Mechanical properties

The mechanical properties of the available products are given in the table below.

Standard Rp0.2 Rp1.0 Rm Elongation Impact strength Rockwell HB HV
MPa MPa MPa % J
Product type: Cold rolled coil and sheet
ASME II A SA-240 ≥ 295 ≥ 650
ASTM A240 ≥ 310 ≥ 690 ≤ 100HRB
ASTM A240 ≥ 295 ≥ 650
IS 6911 ≥ 295 ≥ 650
Product type: Hot rolled coil and sheet
ASME II A SA-240 ≥ 295 ≥ 650
ASTM A240 ≥ 295 ≥ 650
IS 6911 ≥ 295 ≥ 650
Product type: Hot rolled quarto plate
Typical (thickness 15 mm) 320 340 700 50 180
ASME II A SA-240 ≥ 295 ≥ 650
ASTM A240 ≥ 295 ≥ 650
EN 10028-7 ≥ 300 ≥ 340 650-850 ≥ 40
EN 10088-2 ≥ 300 ≥ 340 650-850 ≥ 40
EN 10088-4 ≥ 300 ≥ 340 650-850 ≥ 40
EN 10088-4 -5MEK ≥ 300 ≥ 340 650-850 ≥ 40
IS 6911 ≥ 295 ≥ 650

1)Elongation according to EN standard:A80 for thickness below 3 mm.A for thickness = 3 mm.Elongation according to ASTM standard A2” or A50.

Physical properties

The physical properties at room temperature are shown in the table below. Data according to EN10088 or EN10095.

Density

Modulus

of elasticity

Thermal

exp. at 100 °C

Thermal

conductivity

Thermal

capacity

Electrical resistance Magnetizable
kg/dm3 GPa 10-6/°C W/m°C J/kg°C µΩm
8,1 195 15,8 12 450 1,00 No
Standards & approvals

Outokumpu produce and certify materials to most international and national standards. Work is continuously on-going to get the different grades approved for relevant standards. The most commonly used international product standards are given in the table below.

Standard Designation
ASME SA-240M Code Sect. II. Part A UNS N08926
ASTM A240/A240M UNS N08926; UNS N08926
EN 10028-7, PED 2014/68/EU 1.4529
EN 10088-2 1.4529
EN 10088-3 1.4529
EN 10088-4 1.4529
IS 6911, AMENDMENT NO. 2 ISS 904LN
